SHOWER CHANNEL WATERLINE 700 - (178.070.056.20)

Part Of the Series: Shower channel-No membrane

Type no.: 178.070.056.20

EAN no.: 5705499138429

VVS no.: 155061007

Size: 50x700


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Domestic
Floor Concrete / Tiled
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Outlet Box No
Outlet dia. (mm) 50
Outlet Diameter (Inch) 2
Outlet Direction Vertical
Outlet Placement End
Shape Rectangular
Size (mm) 50x700
Size of Frame (Inch) 2 x 27-1/2
Weight (kg) 1.3
Weight (lbs) 2.87
