CHANNEL 400x3000 END OUTLET - (670FK030-00BA)

Part Of the Series: Channel-No membrane

Type no.: 670FK030-00BA

EAN no.: 5705499129984

Size: 400x3000


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 170
Outlet Box No
Outlet dia. (mm) 160
Outlet Diameter (Inch) 6
Outlet Direction Vertical
Outlet Placement End
Shape Rectangular
Size (mm) 400x3000
Size of Frame (Inch) 15-3/4 x 118-1/8
Weight (kg) 29.83
Weight (lbs) 65.76
