UPPER PART - (710.403.000.01)
×
![]()
Part Of the Series: Upper part-No membrane-300
Type no.: 710.403.000.01
EAN no.: 5705499108224
LVI no.: 3303811
Size: 300x300
UPPER PART
-With screw lock and supporting ring for water trap
-Floor: concrete and tiled
-Frame: 11-3/4 x 11-3/4 inch
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Field of Application | Industrial |
| Floor | Concrete / Tiled |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Number of Screw Holes | 2 |
| Outlet dia. (mm) | 160 |
| Outlet Diameter (Inch) | 6 |
| Shape | Square |
| Size (mm) | 300x300 |
| Size of Frame (Inch) | 11-3/4 x 11-3/4 |
| Weight (kg) | 3.18 |
| Weight (lbs) | 7.01 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
