SHOWER DRAIN CIRCLE - (261.300.110)

Part Of the Series: Drain-Vinyl-155

Type no.: 261.300.110

EAN no.: 5705499105247

VVS no.: 153610416

NRF no.: 3394606

LVI no.: 3305829

Size: Ø155


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Domestic
Floor Vinyl
Load Class EN1253 K3
Load class EN1253(kg) K3
Material AISI 304
Material (EN) EN 1.4301
Minimum Height (mm) 163
Number of Inlets 2 (Ø32/40mm)
Number of Inlets (Inch) 2 (Ø1-1/4 inch, 1-1/2 inch)
Number of Screw Holes 3
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Vertical
Shape Round
Size (mm) Ø155
Size of Frame (Inch) Ø6-1/8
Weight (kg) 1.25
Weight (lbs) 2.76
