INDUSTRIAL DRAIN, LOW - (766.502.110)

Part Of the Series: Drain-No membrane-205

Type no.: 766.502.110

EAN no.: 5705499110463

VVS no.: 153050102

LVI no.: 3303583

Size: Ø205


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Adjustable No
Field of Application Industrial
Floor Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 239
Number of Inlets 0
Number of Screw Holes 0
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Vertical
Shape Round
Size (mm) Ø205
Size of Frame (Inch) Ø8-1/8
Weight (kg) 2.24
Weight (lbs) 4.94
