SHOWER CHANNEL WATERLINE 900 - (398.090.056.20)

Part Of the Series: Shower channel-Sheet membrane

Type no.: 398.090.056.20

EAN no.: 5705499138399

VVS no.: 155063009

RSK no.: 7121706

NRF no.: 3394728

Size: 50x900


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Domestic
Floor Concrete / Tiled
Material AISI 304
Material (EN) EN 1.4301
Membrane Type Sheet Membrane
Outlet Box No
Outlet dia. (mm) 50
Outlet Diameter (Inch) 2
Outlet Direction Vertical
Outlet Placement End
Shape Rectangular
Size (mm) 50x900
Size of Frame (Inch) 2 x 35-3/8
Weight (kg) 4.24
Weight (lbs) 9.35
