CHANNEL 200x2000 END OUTLET - (670DH020-00BA)

Part Of the Series: Channel-No membrane

Type no.: 670DH020-00BA

EAN no.: 5705499129564

Size: 200x2000


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Floor Concrete / Tiled / Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 152
Outlet Box No
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Vertical
Outlet Placement End
Shape Rectangular
Size (mm) 200x2000
Size of Frame (Inch) 7-7/8 x 78-3/4
Weight (kg) 13.16
Weight (lbs) 29.01
