ADJUSTABLE SHOWER DRAIN CIRCLE - (210.300.075)
×
![]()
Part Of the Series: Drain-Vinyl-155
Type no.: 210.300.075
EAN no.: 5705499105049
VVS no.: 153614113
NRF no.: 3394573
Size: Ø155
ADJUSTABLE SHOWER DRAIN CIRCLE
-Floor: vinyl
-Grating: Ø6-1/8 inch
-Outlet: Ø3 inch, horizontal
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Field of Application | Domestic |
| Floor | Vinyl |
| Load Class EN1253 | K3 |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Maximum Height (mm) | 153 |
| Minimum Height (mm) | 123 |
| Number of Inlets | 0 |
| Number of Screw Holes | 3 |
| Outlet dia. (mm) | 75 |
| Outlet Diameter (Inch) | 3 |
| Outlet Direction | Horizontal |
| Shape | Round |
| Size (mm) | Ø155 |
| Size of Frame (Inch) | Ø6-1/8 |
| Weight (kg) | 1.35 |
| Weight (lbs) | 2.98 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
FI - Tyyppihyväksyntäpäätös EUF129-23001919-TH1
BLÜCHER® Drains EPD
NO - PS3199
HACCP Food Safety Programme - Europe
US - NSF/ANSI/3-A 14159-1-Meat and Poultry
SE - RISE 0193-98 Declaration of Conformity - EN1253-001 Declaration of Conformity - BSEN1253-002 PL - Hygienic Certificate - All Products
