ADJUSTABLE SHOWER DRAIN CIRCLE - (210.300.050)
Part Of the Series: Drain-Vinyl-155
Type no.: 210.300.050
EAN no.: 5705499124316
Size: Ø155
ADJUSTABLE SHOWER DRAIN CIRCLE
-Floor: vinyl
-Grating: Ø6-1/8 inch
-Outlet: Ø2 inch, horizontal
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Field of Application | Domestic |
Floor | Vinyl |
Load Class EN1253 | K3 |
Load class EN1253(kg) | K3 |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Maximum Height (mm) | 153 |
Minimum Height (mm) | 123 |
Number of Inlets | 0 |
Number of Screw Holes | 3 |
Outlet dia. (mm) | 50 |
Outlet Diameter (Inch) | 2 |
Outlet Direction | Horizontal |
Shape | Round |
Size (mm) | Ø155 |
Size of Frame (Inch) | Ø6-1/8 |
Weight (kg) | 1.3 |
Weight (lbs) | 2.87 |
-
Approval Information
For approval information, please refer to the below approval certificates.
