INDUSTRIAL DRAIN - (763.502.110)

Part Of the Series: Drain-No membrane-205

Type no.: 763.502.110

EAN no.: 5705499110081

VVS no.: 153050202

RSK no.: 7123995

NRF no.: 3396095

LVI no.: 3303623

Size: Ø205

Download CAD Collections

2d DWG files

3d STP files

Download MasterSpec Documents


Product Specification
Adjustable No
Field of Application Industrial
Floor Resin
Material AISI 304
Material (EN) EN 1.4301
Membrane Type No Membrane
Minimum Height (mm) 213
Number of Inlets 0
Number of Screw Holes 0
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Horizontal
Shape Round
Size (mm) Ø205
Size of Frame (Inch) Ø8-1/8
Weight (kg) 2.48
Weight (lbs) 5.47
