HYGIENICPRO CHANNEL 150x7000 CENTER OUTLET - (676CC070-35EF S)

Part Of the Series: Channel-No membrane

Type no.: 676CC070-35EF S

EAN no.: 5705499137347

LVI no.: 3305698

Size: 150x7000


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Floor Concrete / Tiled / Resin
Material AISI 316L
Material (EN) EN 1.4404
Membrane Type No Membrane
Minimum Height (mm) 565
Outlet Box Yes
Outlet dia. (mm) 110
Outlet Diameter (Inch) 4
Outlet Direction Vertical
Outlet Placement Center
Shape Rectangular
Size (mm) 150x7000
Size of Frame (Inch) 5-7/8 x 275-5/8
Weight (kg) 58.47
Weight (lbs) 128.9
  • Approval Information

    For approval information, please refer to the below approval certificates.
