Part Of the Series: Grating-Drain-305-Vinyl-332

Type no.: 790.273.000.06

EAN no.: 5705499128567

RSK no.: 7123457

NRF no.: 3397196

LVI no.: 3303993

Size: Ø295

Download CAD Collections

2d DWG files

3d STP files

Download MasterSpec Documents


Product Specification
Field of Application Industrial
Load Class EN1253 K3
Load class EN1253(kg) K3 (750)
Load class EN1253(lbs) K3 (1653)
Material AISI 304
Material (EN) EN 1.4301
Minimum Height (mm) 25
Number of Screws 0
Shape Round
Size (mm) Ø295
Size of Frame (Inch) Ø11-5/8
Weight (kg) 1.57
Weight (lbs) 3.46
