HYGIENICPRO GRATING SQUARE - (790.268.000.60 S)

Part Of the Series: Grating-Drain-300

Type no.: 790.268.000.60 S

EAN no.: 5705499138610

Size: 300x300


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Load Class EN1253 R50
Load class EN1253(kg) R50 (5000)
Load class EN1253(lbs) R50 (11023)
Material AISI 316L
Material (EN) EN 1.4404
Minimum Height (mm) 24
Non slip R10
Number of Screws 0
Shape Square
Size (mm) 300x300
Size of Frame (Inch) 11-3/4 x 11-3/4
Weight (kg) 5.36
Weight (lbs) 11.82
  • Approval Information

    For approval information, please refer to the below approval certificates.
