LADDER GRATING SQUARE - (790.168.000.25)

Part Of the Series: Grating-Drain-200

Type no.: 790.168.000.25

EAN no.: 5705499113488

NRF no.: 3396421

LVI no.: 3304043

Size: 200x200


Download CAD Collections

2d DWG files

3d STP files



Download MasterSpec Documents

MasterSpec

Product Specification
Field of Application Industrial
Load Class EN1253 R50
Load class EN1253(kg) R50 (5000)
Load class EN1253(lbs) R50 (11023)
Material AISI 304
Material (EN) EN 1.4301
Minimum Height (mm) 25
Non slip R11
Number of Screws 0
Shape Square
Size (mm) 200x200
Size of Frame (Inch) 7-7/8 x 7-7/8
Weight (kg) 1.72
Weight (lbs) 3.79
