BEND, LARGE RADIUS 87.5° - (825.090.075 S)
×
![]()
Part Of the Series: Bend-87.5-large radius
Type no.: 825.090.075 S
EAN no.: 5705499408850
NRF no.: 2172552
LVI no.: 0256016
BEND, LARGE RADIUS 87.5°
-Diameter: Ø75mm
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Angle (°) | 87.5 |
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Outlet dia. (mm) | 75 |
| Outlet Diameter (Inch) | 3 |
| Weight (kg) | 1 |
| Weight (lbs) | 2.2 |
-
Approval Information
For approval information, please refer to the below approval certificates.
DK - VA 2.12/19349 EuroPipe DS432
US - IAPMO File No.3247-EuroPipe
HACCP Food Safety Programme - Europe
BLÜCHER® EuroPipe EPD Bureau Veritas, 02375-I0 Pipes & Fittings MARINE - R4547 NATO CODIFICATION SYSTEM TÜRK LOYDU - 25041616077231247 PL - Hygienic Certificate - All Products DNV - TAP0000023-rev5, Sanitary discharge pipes RINA -MAC320524XG EuroPipe Achilles Certificate - 46702 Lloyds Register LR22419510TA ABS - LD1716353-PDA
